Illustrative image; not for confirming a model or configuration.
BOSS Roll Taps (Formex - Forming Taps) produce internal threads by material forming without generating chips. The forming process provides a smooth rolled thread surface, high thread strength and improved tap durability.
Contact us to choose a configuration
Price, stock and lead time are confirmed during consultation.
BOSS Roll Taps are designed to produce internal threads by forming the material rather than cutting and removing chips.
Unlike conventional cutting taps, the forming process generates no chips during tapping. The material is displaced and formed according to the thread profile, producing a rolled thread surface with a smooth and consistent appearance.
According to the BOSS catalog, the material structure is not destroyed during forming, which can increase thread strength by approximately 30% while maintaining consistent accuracy under the specified conditions. The larger core diameter of Roll Taps also increases durability and torque resistance, helping reduce the risk of tap breakage. Markdown đã dán (1)
BOSS Roll Taps are available in configurations for both blind holes and through holes. Type B is specified for blind holes with a 2-thread chamfer, while Type P is specified for through holes with a 4-thread chamfer. Markdown đã dán (1)
The catalog includes TiN Coating – Standard Thread, TiN Coating – Long Thread, and TiCN Coating – Long Thread versions, covering Metric and US thread sizes.
Chipless internal thread forming
Through-hole threading
Blind-hole threading
Metric thread applications
US thread applications
Precision mechanical components
Applications requiring consistent thread surfaces
Applications requiring high thread strength
Series and mass production
| Specification | Value |
|---|---|
| Brand | BOSS |
| Brand Origin | Germany |
| Product Group | Taps |
| Product Series | Roll Taps |
| Machining Method | Thread forming |
| Chip Generation | None |
| Type B | Blind hole, 2-thread chamfer |
| Type P | Through hole, 4-thread chamfer |
| Metric Standard | Metric Thread |
| US Standard | US Thread ANSI B1.1 |
| Coating | TiN / TiCN depending on series |
| Versions | Standard Thread / Long Thread |
| Metric TiN Standard | M2×0.4 to M16×2.0 |
| Metric TiN Long | M2×0.4 to M6×1.0 |
| Metric TiCN Long | M1×0.25 to M6×1.0 |
| Thread Surface | Rolled surface |
| Forming Process | Chipless |
| Thread Strength | Up to approx. 30% increase stated in catalog |
| Core Diameter | Larger core for increased durability and torque |
